筒管規格

Bobbin spec

6"(170mm)

結構

Layout

雙面機，每臺（12-96）錠

Double-sided, one-machine has （12-96） spindles

電源

Power Supply

三相380V 50/60HZ/Three phases 380V 50/60HZ

驅動

Transmission

單錠獨立交流馬達驅動

Every spindle is driven by a AC motor individually

消耗功率

Power Comsumption

0.09千瓦/錠/0.09KW/spindle

成型筒子

Take-up package

圓形柱(0°)/Cylinrical (0°)錐形；4°20, 5°57, 9°15 cone

筒子直徑

Package Diameter

最大200和290毫米／Max．200and 290mm

紗線速度范圍

Yam speed

300-1000m/min

電子防重疊裝置

Electrical wobble frequency anti-patterning function

變頻器控制／Control by the lnverter

定長裝置

Length counting device

可編程控制器（PLC）集中控制/顯示計長

Controlled and displayed by PLC

張力器

Yarn tension and waxer adjusting device

每錠配置旋轉自清潔張力器和上臘

Every spindle has a self-cleaning yarn tension and waxer adjusting device

機械清紗裝置

Slub-Catcher

每錠配置可微調機械清紗刀

Every spindle has a Mechanical Slub-Catcher

斷紗自停裝置

Yarn break control device

電子斷紗自停

The spindle will stop when the yarn breaks by a yambreak control device

調速裝置

Speed Regulation

變頻調速/By inverter

筒紗軟邊橫動裝置

Anti-hard edge device

機械式/Mechanically/適合松式/suitable soft winder

電子式清紗裝置

Electronic Slub-Catcher

可選配/Ordered separately

空氣捻接器

Splicer

可選配/Ordered separately

照明系統（帶燈）
Lighting system

可選配/Ordered separately

外形尺寸（毫米）

Dimensions

13700(長/length)×1050(寬/width)×1650(高/height)mm
