我公司生產圓網印花零部件已有二十多年的歷史，在此基礎上與國外合作生產的圓網印花機在電器控制及烘房部分作了改進，使圓網印花機更趨完美。紅外對邊裝置進布、貼布裝置、印花采用機械傳動和交流伺服獨立傳動兩種，刮印采用氣動模塊集中控制，電氣自動控制色漿液面。
On the basis of more than 20 years experience of accessory production,our company coo-perates with foreign partnership to generate the round-net printing machine,whose improvement on the electrical control and dried-room keep the printing machine better.Units of infrared putting margin,pasting fabric,printing are transmitted by the mechanical and independent servo exchange approach.Scrapend-printing is controlled by pneumatic module;the liquid level of pulp colour is controlled automatically by electric.

主要規格

MAIL SPECIFICATIONS
機械公稱寬度：1800-3000mm
（最大印花寬度1650-2850mm）
機械車速：4-80m/min
印花主機：
圓網周長：640AL 819AL 914AL 1018AL
印花套色素：4-16套
對外精度：≤0.2mm
刮印方式：刮刀或磁棒
進布方式：布車進布，面布操作臺在左手，漿泵在右手邊
電器控制及操作：PLC控制；人機介面操作
印花漿料供應：不銹鋼內齒輪泵供漿。
印花導帶：進口
Mechanical nominal width：1800-3000mm
(Maximum printing width：1650-2850mm)
Mechanical speed:4-80m/min
Printing Host:
Round-net circumference: 640AL 819AL 914AL 1018AL
Number of priting set: 4-16sets
Precision: ≤0.2mm
Way of Scraped-printing: scraper or magnetic-stick
Way of fabric-input: fabric-input by machine,fabric and starching pump are respectively on the left and right of control board
Electrical control & operation: controlled by PLC; operated with GUI
Starch supply for printing: starch supplied by Hg inside the stainiess gear
Printing belt: imported
